FIBC Bulk Bags: Anti-Static, Conductive, Aluminum Foil Ton Bags
Industrial-Grade Flexible Intermediate Bulk Containers for Chemical, Mining & Food Industries
FIBC Product Center Overview
FIBCs (Flexible Intermediate Bulk Containers), commonly known as ton bags or bulk bags, are the core product line of BridgeX Pack. Our ton bags are not off-the-shelf products; they are engineered solutions composed of multiple technical parameters. Based on your material characteristics (powder/granule/lump, flammable/hygroscopic), filling method, and transport environment, we provide complete solutions from structural selection to functional customization.
All products are manufactured under ISO 9001, with UN hazardous goods and food-grade certifications available. Annual capacity of 5 million units, exported to 100+ countries.
FIBC Product Types
Six main categories to meet every bulk packaging need
Pallet Ton Bags
Soft pallet design with forklift sleeves. Ideal for feed, seeds, chemicals. 1-3 tons capacity.
U-Panel / Square / Circular
Three classic body structures. U-panel economical, 4-panel square precision, circular for powders.
Aluminum Foil FIBC
Ultimate moisture-proof. WVTR <0.1 g/m²/day. For lithium battery materials, hygroscopic chemicals.
Conductive FIBC Type C/D
Explosion-proof ton bags. Type C (must ground) and Type D (no ground). IEC 61340-4-4 compliant.
Anti-static FIBC Type B
Economical static protection. No grounding required. Breakdown voltage <6 kV.
Custom FIBC
Full-process customization. ODM/OEM. Special dimensions, multi-function composites, brand printing.
Technical Parameters
| Parameter | Specification |
|---|---|
| Safe Working Load | 0.5 – 3 tons |
| Safety Factor | 5:1 / 6:1 / 8:1 optional |
| Dimensions | L×W×H 50–120 cm per dimension, tolerance ±1 cm |
| Body Structure | U-Panel / 4-Panel / Circular / Baffled |
| Material | 100% virgin PP, UV stabilization optional |
| Top Design | Fill spout / Open top / Duffle top / Flat with tie strings |
| Bottom Design | Discharge spout / Flat bottom / Conical bottom |
| Lifting System | Cross-corner loops / Side-sewn loops / Single loop / Combination |
| Printing | Up to 8-color flexo, Logo, barcode, QR, batch traceability |
| Functional Add-ons | UV stabilization, anti-static, conductive, breathable panels, Al foil barrier, PE liner, RFID tags |
Typical Applications
- Chemicals: TiO₂, carbon black, plastic resin pellets, pigments, dyes
- Food: Flour, sugar, starch, grains, food additives
- Mining: Silica sand, iron ore concentrate, coal, mineral sands
- Construction: Cement, dry mortar, sand, aggregates
- New Energy: Lithium powder, NCM precursors, graphite
- Agriculture: Seeds, fertilizer, feed pellets
Get Your Custom FIBC Solution
Contact our engineering team for a tailored bulk bag solution. Free samples available.
